Heavy Duty Cost-effective Porous Hollow Block Moulding Machine QT18-15
The Yixin Machinery QT18-15 is a heavy-duty, cost-effective porous hollow block moulding machine designed for high-efficiency production. It features a robust structure with a durable vibration table and synchronized vibration shaft, ensuring uniform force distribution for consistent block density and strength. The machine utilizes advanced hydraulic pressure and PLC intelligent control, enabling automated operation and precise production. Suitable for large-scale projects, it produces various block types, including hollow, solid, and interlocking blocks, using materials like cement, fly ash, and sand. Its high output capacity and low maintenance make it ideal for industrial construction applications.
Model :
Yixin Machinery Heavy Duty QT18-15Machine Dimension :
12800*5500*2800(MM)Pallet Size :
1350*1350(MM)Cycle Time :
15-25(S)Vibration Force :
120(KN)Vated Pressure :
21(MPA)Power :
100(KW)Heavy Duty Cost-effective Porous Hollow Block Moulding Machine QT18-15
Reference video of Heavy Duty Cost-effective Porous Hollow Block Moulding Machine QT18-15:
The QT18-15 is a heavy-duty, cost-effective porous hollow block moulding machine designed for high-volume production of lightweight porous hollow blocks. Featuring an advanced hydraulic system and intelligent PLC control, it ensures precise shaping, uniform density, and excellent thermal insulation properties. Its robust construction and high vibration force deliver reliable performance for continuous operation. Quick mold change enables flexible production of various porous block sizes. A reference video is available to demonstrate the complete moulding cycle, from material feeding to finished block output. Ideal for eco-friendly construction projects seeking cost-effectiveness, durability, and superior porous block quality.
Production Data
| Block Type | Specification（mm） | Qty/Pallet | Qty/Hour | Qty/8 Hours |
| Hollow Block | 400*200*200 | 18 | 2852 | 22816 |
| Solid Brick | 240*115*53 | 100 | 27500 | 220000 |
| Holland Paver | 200*100*60 | 66 | 11688 | 93504 |
| Zigzag Paver | 225*112.5*60 | 50 | 9900 | 79200 |
Product Details
Block Display
The QT18-15 features an integrated block display system designed for efficient inspection of finished porous hollow blocks. This system allows operators to easily examine surface finish, dimensional accuracy, wall thickness consistency, cavity alignment, edge integrity, and color uniformity before stacking and packaging. Equipped with adjustable LED lighting and smooth roller tables, it protects block surfaces during movement while enabling thorough visual quality checks. The user-friendly layout supports quick sampling, quality control documentation, and customer viewing. Ideal for cost-effective, high-volume porous hollow block production, this block display system enhances quality assurance, reduces defective output, and ensures only high-quality blocks proceed to curing and shipping.
Block Type
The QT18-15 is capable of producing a wide range of porous hollow block types to meet diverse construction needs. These include standard porous hollow blocks for load-bearing walls, lightweight insulation blocks for energy-efficient buildings, permeable paving blocks for drainage systems, and customized cavity designs for specific project requirements. The machine also produces interlocking porous blocks for retaining walls and garden landscaping. Quick mold change allows seamless switching between different block types and sizes. Ideal for cost-effective, high-volume production, the QT18-15 delivers consistent quality, excellent thermal insulation, and superior structural strength across all porous hollow block varieties.
| FAQ |
|
1.What routine maintenance is required? Daily lubrication, hydraulic oil level checks, air bag pressure inspection, vibration motor checks, and cleaning of mold and pallet areas. |
|
2.How is the machine packaged? Heavy-duty steel crating with anti-rust treatment, waterproof wrapping, and shock-absorbing supports. |
|
3.Is installation support provided? Yes. We provide installation guidance, commissioning support, and operator training on-site or via video. |
|
4.How does the machine ensure consistent wall thickness? The precision guiding system and advanced vibration technology ensure uniform material distribution around core pins, resulting in consistent wall thickness and structural integrity across all hollow blocks. |
|
5. Is after-sales service available internationally? Yes, we have a global after-sales service network. We provide remote technical support, video troubleshooting, and on-site service arrangements when necessary. Spare parts can be shipped internationally with fast delivery options. |
